CAT5 CAT5E wire outdoor LAN cable
CAT5 CAT5E wire outdoor LAN cable
Item Number:CAT5 CAT5E wire outdoor LAN cable
- Model: CAT5 CAT5E wire outdoor LAN cable
- Size: 24AWG Soild(0.46mm-0.51mm)/Stranded
- Color: White/Blue/Black/Gray/Custom
- Insulation: PE
- Shield: Unshielded
- Jacket: PE/Double PE
- Packing: 30.5M(100FT), 305M(1000FT)/CTN/Custom
- OD: 5.2mm/Custom
- Conductor Material: Bare Copper or CCA
- Drain wire: None
Environmental Specifications:
Environmental Space – Non-plenum
Flame Test Method – CMR
Installation Temperature – 0 °C to +60 °C (+32 °F to +140 °F)
Operating Temperature – -20 °C to +60 °C (-4 °F to +140 °F)
General Specifications:
Cable Type
Outdoor U/UTP (unshielded)
Pairs, quantity
4
Cable Component Type
Horizontal
Conductor Gauge, singles
24AWG
Conductor Type, singles
Solid
Characteristics:
- The transmission speed is very fast. Compared to other types of network cables, the transmission speed of the Super Five network cables will be faster, reaching 10 Mbps.
- The manufacturing process is also very good, which can effectively reduce signal interference. Moreover, they are all made of copper wires twisted together, so the electrical conductivity is very good.
- There are many brands sold on the market, so everyone must choose a large brand to ensure the quality of the network cable.
- Suitable for indoor applications
In general, the network cable CAT5/CAT5E Outdoor has several advantages, such as well overall performance, high-cost performance, and relatively low difficulty in construction and maintenance. Choosing it will not disappoint you.
Contact Us Now
Categories
CAT5 CAT5E wire outdoor LAN cable
| Electrical Specifications | |
| ANSI/TIA Category | 5/5e Outdoor |
| dc Resistance Unbalance, maximum | 5 % |
| dc Resistance, maximum | 9.38 ohms/100 m |
| Mutual Capacitance | 5.6 nF/100 m @ 1 kHz |
| Nominal Velocity of Propagation (NVP) | 69 % |
| Operating Frequency, maximum | 200 MHz |
| Operating Voltage, maximum | 80 V |
| Transmission Standards | ANSI/TIA-568-C.2 CENELEC EN 50288-3-1 ISO/IEC 11801 Class D |
| Dielectric Strength, minimum | 1500 Vac 2500 Vdc |
Description
What is Outdoor CAT5/CAT5E cable？
Elevate your outdoor network setup with our UV-resistant outdoor Cat5e cable. This robust cable is CMX-rated, making it ideal for exterior installations around your home or business. It's specifically designed for high-speed gigabit connectivity, whether it's linking rooms within a building, extending across to another structure, or reaching a remote location on your property. The cable's CMX jacket is engineered for both waterproofing and UV resistance, ensuring reliable performance even in harsh outdoor conditions.
- Optimized for outdoor use
- Waterproof to withstand rain exposure
- UV-resistant, ensuring durability in direct sunlight
- Available in bulk lengths of 250ft, 500ft, and 1000ft for tailored cable runs
Our outdoor Cat5e cable is crafted for reliable everyday performance. Capable of supporting speeds up to 1 Gigabit and bandwidths up to 350 MHz, it's an economical choice when you don't need PoE (Power over Ethernet) for distances exceeding 150 feet, or if future network upgrades aren't planned. This cable is particularly advantageous for industrial settings, such as factories looking to upgrade outdated Cat5 cables for machinery that doesn’t demand high bandwidth. Its slim profile also makes it a suitable option for older buildings where space for cabling is limited.
We offer this bulk network cable in 500ft or 1000ft Cat5e cable boxes, available in a diverse range of colors and jacket types to suit various installation requirements. Whether upgrading older infrastructures or establishing new outdoor networks, our Cat5e cable combines performance, resilience, and versatility for a range of outdoor networking needs.
Outdoor CAT5/CAT5E Specification
| Product Construction | |||||
| Conductor | Material | Pure copper | |||
| AWG | 24 | ||||
| Diameter（mm） | 0.50 | ||||
| Insulation | Material | PE | |||
| Average Thickness（mm） | 0.19 | ||||
| Minimum Thickness（mm） | 0.17 | ||||
| Diameter（mm） | 0.89 | ||||
| pair Twist Diameter（mm） | 1.78 | ||||
| Cable Diameter（mm） | 3.70 | ||||
| PEL（mm） | w=19,h=0.015 | ||||
| Rip-cord | 1*3D | ||||
| Jacket | Material | Double PE | |||
| Average Thickness（mm） | 0.55 | ||||
| Minimum Thickness（mm） | 0.50 | ||||
| Diameter（mm） | 5.60 | ||||
| Color | |||||
| Insulation Wire | Blue*White/Blue | Orange*White/Orange | |||
| Green*White/Green | Brown*White/Brown | ||||
| Jacket | According to the customer's requirement | ||||
Outdoor CAT5/CAT5E Electrical Characteristic
| Electrical Characteristic | ||||||
| Impedance Ω | Propagation Delay Skew ns/100m | Capacitance Unbalance | Conductor Resistanc@20℃ Ω/km | Unbalance Resistance % | ||
| 100±15 | <=45 | <=330 | <=9.5 | <=5 | ||
| Frequency MHZ | Return Loss >=dB | Attenuation <=dB/100m | Next >=dB/100m | PS Next >=dB/100m | Elfext >=dB/100m | PS Elfext >=dB/100m |
| 1 | 20.0 | 2.0 | 65.3 | 62.3 | 63.8 | 60.8 |
| 4 | 23.0 | 4.1 | 56.3 | 53.3 | 51.7 | 48.7 |
| 8 | 24.5 | 5.8 | 51.8 | 48.8 | 45.7 | 42.7 |
| 10 | 25.0 | 6.5 | 50.3 | 47.3 | 43.8 | 40.8 |
| 16 | 25.0 | 8.2 | 47.3 | 44.3 | 39.7 | 36.7 |
| 20 | 25.0 | 9.3 | 45.8 | 42.8 | 37.7 | 34.7 |
| 25 | 24.3 | 10.4 | 44.3 | 41.3 | 35.8 | 32.8 |
| 31.25 | 23.6 | 11.7 | 42.9 | 39.9 | 33.9 | 30.9 |
| 62.5 | 21.5 | 17.0 | 38.4 | 35.4 | 27.8 | 24.8 |
| 100 | 20.1 | 22.0 | 35.3 | 32.3 | 23.8 | 20.8 |
CAT5 CAT5E Outdoor Mechanical Characteristic
| Mechanical Characteristic | Product Standard | ||||||
| Testing Object | Jacket Material | Rated Temperature（℃） | 90/-55 | ||||
| Testing Material | PE | YD/T1019-2001 | Meet | ||||
| Aging Condition（℃*hrs） | 115*168 | UL/C(UL)/ETL | |||||
| Before Aging | Tensile Strength（Mpa） | >=16.5 | ANSI/EIA568C.2 | ||||
| Elongation(%) | >=300 | ISO/IEC 11801 | |||||
| After Aging | Tensile Strength（Mpa） | >=85% of unaged | Packaging | 305M/Box/Reel | |||
| Elongation(%) | >=50% of unaged | Printing | According to the customer's requirement | ||||
| Cold Bending（-20±2℃*4hrs） | No crack | ||||||
Can Cat5e be used outdoors?
Applicability for Outdoor Environments: Yes, Cat5e cables can be utilized outdoors, but selecting the right type is crucial. Outdoor Cat5e cables must be specifically rated for external use, featuring a jacket with UV protection and water-resistant properties. For direct ground installation, these cables should be either armored or burial-rated.
Distance Constraints: The length limit for outdoor Cat5e cables mirrors that of indoor variants, which is 100 meters or 328 feet. For extended cable runs beyond this range, signal boosters are necessary. As an alternative, fiber optic cables, which offer superior long-distance performance compared to Cat5e, can be considered.
What is the difference between indoor and outdoor Cat5?
Indoor vs. Outdoor Cat5e Differences: Indoor and outdoor Cat5e cables are tailored to different environmental needs. The main distinction lies in UV resistance and water repellency. Indoor Cat5e cables typically have a riser or plenum-rated jacket unsuitable for external conditions and lack UV protection. In contrast, outdoor Cat5e cables are equipped with a High-Density Polyethylene (HDPE) jacket for UV defense, often accompanied by a water-blocking gel to avert moisture-related corrosion.
How do I protect my Cat5 cable outside?
Securing Cat5e Cables Outdoors: To protect Cat5e cables in outdoor settings, begin with a cable that is rated for such applications. If you're faced with harsh environmental factors like excessive moisture or sunlight, consider installing the cable within a conduit. For cables suitable for direct burial, lay them in the ground or use a conduit as per the specific installation requirements.
Is there an outdoor Cat5 cable?
Availability of Outdoor Cat5e Cables: Outdoor Cat5e cables are indeed available. Providers like Discount Low Voltage offer a selection of outdoor Cat5e and direct burial cables. These cables should be installed about eight inches underground, maintaining a safe distance from underground power lines.
How long will Cat5 cables last outside?
The durability of Outdoor Cat5e Cables: The longevity of Cat5e cables outdoors depends on multiple factors, including their outdoor rating and construction. Outdoor-rated Cat5e cables, featuring an HDPE jacket, are built to withstand UV rays and environmental elements. The cable's quality, exposure to UV light, temperature variations, and installation quality all impact its durability. Properly installed in a dry, mild climate, outdoor Cat5e cables can last well beyond a decade.
What is the difference between indoor and outdoor?
Sunlight Resistance of Outdoor Network Cables A key trait of outdoor-rated network cables, such as outdoor CAT5 or Cat5e cables, is their UV-resistant jacket. These jackets are typically crafted from polyethylene (PE) or polyvinyl chloride (PVC). In contrast, indoor-rated cables lack UV protection, leading them to deteriorate and crack when exposed to prolonged direct sunlight.
Moisture Resistance in Outdoor Ethernet Cables Outdoor cables are also distinguished by their waterproof characteristics, offering protection from various weather elements. The PE or PVC jackets of these cables exhibit low water absorption, ensuring durability. CMX-rated outdoor cables, for instance, can safeguard network connections, even when the cable jacket is submerged in water.
Oil Resistance in Outdoor Cables For more specialized environments, there are outdoor cables resistant to oil. These are fabricated from materials that withstand corrosion or degradation in the presence of the majority of chemicals or oils typically found in industrial settings.
Underground and Overhead Installation Compatibility Outdoor cables are versatile, with certain types like direct burial cables designed for underground installation. These cables are "flooded," which means their core is infused with a gel that blocks moisture intrusion. This feature enables outdoor CAT5 and Cat5e cables to be used in demanding environments, both underground and overhead, where indoor cables would not be suitable.
