Cat 6a FFTP Patch Cable

Description

What is CAT6A F FTP Patch Cable?

CAT6a FFTP Patch Cords, developed and produced by leading cat6a fftp patch cable manufacturers, are meticulously crafted to surpass the stringent standards set by ISO, CENELEC, and TIA, including the ANSI/TIA-568-C.2 Standard of 2009 and ANSI/TIA-568.0-D Standard of 2017. These cables deliver Class FA link and channel performance, supporting a wide array of applications as detailed and proposed within these standards. Their outstanding performance is further validated by ETL component verification.

Key Features of CAT6a FFTP Patch Cord:

• Ideal for structured premises cabling.
• Facilitates transmission of both digital and analogue voice and data signals.
• Particularly suitable for all Class EA applications.
• Compatible with ISDN, Ethernet 10 Base-T, Fast Ethernet 100 Base-T, Gigabit Ethernet 1000Base-T, and 10G Base-T (IEEE 802.3).

Each patch cord in this series is ETL verified, exceeding the EIA/TIA 568B standards for 24 AWG stranded conductor unshielded twisted-pair applications. These cords provide a remarkable 250MHz performance. Designed with flexibility and durability in mind, they feature stranded wire and are encased in a robust PVC jacket. The RJ-45 connectors are shielded with innovatively designed boot covers at each end of the patch cord, indicating the length in use.

Advantages of Using CAT6a FFTP Patch Cord:

• Maximizes pair separation, enhancing key electrical performance parameters.
• Eliminates both internal and external alien crosstalk, ensuring clearer signal transmission.
• Surpasses CAT6A UTP cable performance, offering greater headroom and reliability.
• Provides exceptional signal isolation, minimizing interference.
• Ensures superior EMI/RFI protection, enhancing signal integrity.
• Enhances data security, making it a reliable choice for sensitive applications.

CAT6 vs. CAT6A Cabling: An Analysis

CAT6 and CAT6A cabling, both staples in Gigabit Ethernet setups, cater to a range of data rates including 10BASE-T, 100BASE-TX, 1000BASE-TX, and 10GBASE-T. The distinction lies in the lowercase 'a' in CAT6a, signifying 'augmented'. This small typographical difference heralds significant variations in their performance and physical characteristics.

Typically, CAT6 cables feature 23 AWG wire conductors and are capable of supporting data speeds up to 10Gbps at 250MHz. However, at this speed, their effective range is limited to about 33-35 meters. CAT6A, also equipped with 23 AWG wire conductors, enhances performance substantially, offering data transmission at 500MHz. Importantly, CAT6A maintains the 10Gbps standard over a complete 100-meter span. It's noteworthy that CAT6A cables are generally thicker than CAT6 due to additional plastic insulation, resulting in greater space consumption in patch panels.

Can CAT6A Cables Be Used on CAT6 Patch Panels?

Using an Ethernet patch panel is a prevalent solution for organizing CAT6 and CAT6A cabling. Typically, CAT6 cables pair with CAT6 patch panels, while CAT6A cables align with CAT6A patch panels. Despite this, the functional differences between CAT6 and CAT6A patch panels are minor. The question then arises: is it feasible to install CAT6A cables on a CAT6 patch panel?

Compatibility and Safety Considerations

Since CAT6A is an advanced version of CAT6, they both utilize the same RJ45 connectors, allowing CAT6A cables to fit into CAT6 patch panels. However, considering the larger size and minimum bend radius of CAT6A cables, special attention is required during installation. This is particularly relevant when dealing with a 48-port CAT6 patch panel, where the thicker CAT6A cables may be prone to bending, potentially compromising safety and cable integrity.

Functionality and Risks

The core functionality, determined by the conductors, suggests that CAT6 patch panels should theoretically accommodate CAT6A cables, as they share RJ45 conductors. Nonetheless, given the physical and safety concerns outlined, this is not an entirely risk-free proposition.

Conclusion

In essence, while CAT6A cables can technically be integrated into CAT6 patch panels, this setup is not without its drawbacks. For experimental or home use, this might be acceptable. However, for applications in data centers or critical business infrastructure, it's advisable to use the appropriate pairing to avoid potential cable damage and subsequent business risks. For further insights into optimal cabling infrastructure design or selection, feel free to reach out at vance@ycable-electronics.com.

CAT6A FFTP Patch Cord Manufacturer In China

YCABLE ELECTRONICS, established in 2018, has rapidly become a distinguished provider of communication network cables in China. Our diverse range of products encompasses LAN cables, bulk cables, patch cables, fiber optic cables, fiber optic patch cords, PLC splitters, and numerous other networking accessories, alongside comprehensive network design solutions.

In our product portfolio, we proudly feature the CAT6 FFTP and CAT6A FFTP patch cords. These cords are known for their advanced shielding technology, enhancing signal protection and network reliability. Particularly, the CAT6A FFTP patch cord stands out with its 500 MHz bandwidth and 10G transmission speed. Rigorously tested in independent laboratories, our CAT6A patch cords have garnered ETL & Delta certifications. Their unique design includes a snagless and slender RJ45 plug molding boot that not only safeguards the RJ45 connector but also seamlessly fits into 1U 48-Port high-density patch panels. We recommend a 50U" gold plating on the terminal to ensure superior transmission quality. These flexible and robust CAT 6A Patch Cords facilitate high-speed data transfers across various platforms, including server applications, cloud services, and video streaming. All our CAT6A patch cables align with ISO/IEC 11801:2011, ANSI/TIA-568.2-D standards, and have UL certification.

The Excel Category 6A (Augmented Category 6) patch leads redefine the benchmarks of copper infrastructure performance. Tailored to meet current ISO and EIA/TIA standards for Class Ea augmented Category 6A performance, these products aim to provide consistent, high-quality network performance, supporting emerging applications such as 10GBase-T and 10 Gigabit Ethernet.

Each Excel Category 6A patch lead comprises four twisted pairs of 26AWG stranded copper wires. An aluminium/polyester foil tape individually screens each pair. These pairs are then cabled together, with varying lay lengths to maximize performance. The cables are terminated with staggered pin RJ45 Screened plugs, and each lead is equipped with colour-coded slimline moulded boots, ideal for high-density router or switch blade environments.
