LC-LC Optical Fiber Patch Cord

Description

What is Patch Cord Fiber Optic LC LC?

Fiber Optic Patch Cord, commonly referred to as a Fiber Optic Patch Cable or Fiber Jumper Cable, is a specialized fiber optic cable with fiber optic connectors on each end. Its primary usage zones include linking computer workstations to outlets and interfacing with fiber optic patch panels or optical cross connect distribution centers. Notably, Fiber Optic Patch Cords are tailored for indoor environments only.

Patch Cord Fiber Optic LC-LC

This Patch Cord is a specific type of fiber optic cable employed for connecting one device to another to facilitate signal transmission. LC in LC-LC Fiber Patch Cord signifies Lucent Connector, a compact, small form-factor fiber optic connector, approximately half the dimension of an ST connector.

Characteristics:

• Reduced insertion loss, augmented return loss
• Compact, lightweight, densely packed connection
• Precision-engineered, standard plastic composition
• High reliability and consistency
• Excellent in repeatability and interchangeability

Applications:

• Diagnostic tools
• FTTX+LAN systems
• Fiber optic-based CATV
• Optical communication frameworks
• Telecommunication networks

LC-LC Patch Cord

The LC-LC Fiber Optic Patch Cord is a compact and versatile patch cable, extensively utilized in a range of network environments. These include telecommunications networks, local area networks (LANs), data processing networks, device terminations, and distribution within premises. LC-LC Patch Cords are engineered to provide swift Ethernet connectivity in Gigabit and ATM setups, optimized for limited spatial configurations.

Addressing the Needs for SFF Solutions

LC connectors in these cords are designed with a mere 1.25mm diameter ferrule, an advantageous feature for fiber optic networks with high density. These connectors are produced in accordance with IEC 61754-20 standards, catering to high-density connections such as those found in SFP, XFP, and SFP+ transceivers.

Singlemode or Multimode LC-LC, Riser or Plenum Rated

YCABLE ELECTRONICS presents an array of LC-LC fiber optic cable assemblies, including single mode (9/125 OS1, OS2), duplex, and multimode (50/125 and 62.5/125) variations. These are available for both riser and plenum applications, with customization options offered through our OEM/ODM services for LC-LC Patch Cords.

Ease of Connection

The LC-LC Patch Cords are built for easy, snap-in connections, equipped with locking mechanisms akin to the retaining tabs found in RJ45 connectors. This design simplifies the process of connecting and disconnecting the connector from devices. The locking tabs are robustly constructed to withstand pulls, strains, snags, and impacts during cabling installations and maintenance routines.

Certified and Low-Loss Fiber Assembly

Each of our patch cords undergoes a stringent 100% optical inspection and testing regimen, ensuring an insertion loss that does not exceed 0.02 dB.

YCABLE ELECTRONICS fiber optic cables are known for their rapid data transmission rates, minimal signal loss, and superior security over traditional copper cables. Their key benefits include high-bandwidth capacity and the ability to transmit data over considerable distances with minimal degradation. Our range spans from high-speed, long-distance single mode cables to shorter-distance, cost-effective multi-mode cables, encompassing a complete spectrum of fiber optic solutions tailored to specific requirements.

• Superior Transmission Distance Optical systems can easily exceed 100 kilometers (62 miles).
• Enhanced Security Optical fiber cables are secure as signal detection requires direct access to the fiber, making them appealing to entities with significant security needs.
• No Metallic Components These cables are immune to electromagnetic interference, suitable for areas near utility lines, power lines, railroad tracks, and high lightning-strike zones.
• Compatible with single-mode fiber applications Supports high
• bandwidth for long distances Low signal degradation and high data transfer rates Ideal for 10G Ethernet applications and beyond

LC LC Optical Fiber Patch Cord Classification

Ultra Low Loss LC LC Optical Fiber Patch Cord

Ultra Low Loss LC LC Optical Fiber Patch Cords stand out as one of the top-tier fiber patch cables. These cables are characterized by their durable, single-piece body connectors, featuring a latch trigger up to four times stronger than standard variants. While typical LC fiber cables have an insertion loss of 0.3 dB, these ultra low loss versions boast a mere 0.12 dB insertion loss. This results in superior performance and reduced power consumption. They are available in both single mode and multimode types, with Grade B connectors ensuring minimal insertion loss and return loss, thus reducing error codes and signal degradation.

Armored LC LC Optical Fiber Patch Cord

Armored LC LC Optical Fiber Patch Cords maintain the characteristics of standard LC fiber patch cords but offer enhanced robustness. They are constructed using armored fiber optic cables, providing resistance against damage from rodent bites, pressure, or twisting. Despite their robust nature, these cables remain as flexible as standard ones and are resistant to breakage when bent. Their outer diameter is comparable to standard LC fiber patch cables, ensuring space efficiency.

Mode-Conditioning LC LC Optical Fiber Patch Cord

Mode-Conditioning LC LC Optical Fiber Patch Cords are an amalgamation of multimode and single mode fiber cables with calibration. These cords, structured like typical duplex LC patch cables, facilitate easy installation without requiring additional assemblies. They are particularly designed for long-wavelength Gigabit Ethernet applications. These cables are ideal in situations where standard multimode LC patch cords are incompatible with certain 1G/10G optical modules, offering a cost-effective solution to upgrading fiber plants. Common configurations include LC to LC, LC to SC, and LC to FC connectors.

LC Fiber Adapter & Patch Panel Solutions

Fiber optic adapters, or couplers, are employed to connect two fiber patch cables. The LC fiber adapter incorporates a self-adjusting mechanism to fit patch panels of varying thickness (1.55 to 1.75 mm). These adapters come in single mode, multimode, simplex, and duplex formats. The simplex adapter connects one LC connector pair, while the duplex adapter links two LC connector pairs within a single module space.

Fiber patch panels, or fiber distribution panels, are available in various rack sizes like 1U, 2U, etc., with 1U being the most common in data centers. The number of ports on these panels is variable, ranging from 12 to over 72. LC fiber adapters and patch panels are ideal for high-density fiber cabling, with the option to pre-load or unload LC fiber adapters for both single mode and multimode fibers. This flexibility makes them suitable for server rooms, data centers, and other high-density fiber installations.

LC Fiber Attenuator Solution

LC fiber attenuators are prevalent devices in LC systems. An LC optical attenuator is a passive component used to decrease optical signal power levels in networks using erbium-doped amplifiers. Available in both fixed and variable types, these attenuators come in different attenuation levels. For example, an LC 1dB fiber attenuator, equipped with an LC fiber connector, reduces fiber power levels by 1dB. For comprehensive insights, it's advised to refer to guidelines on Fixed Fiber Optic Attenuators.

LC LC Optical Fiber Patch Cord Manufacturer In China

Deciphering the LC LC Optical Fiber Patch Cord

When delving into the world of fiber optics, "LC LC Optical Fiber Patch Cord" is a term that frequently emerges. But, what exactly is encapsulated in "LC," and why does it matter? The acronym "LC" signifies Light Coupler, noted for its Small form factor and specialized Ferrule. This SFF (small form-factor) connector is a cornerstone in contemporary data centers and LAN cabling landscapes. This discussion aims to uncover the diverse aspects of LC connectors and underscore their pivotal importance.

Mechanics of an LC LC Optical Fiber Patch Cord

The essence of an LC LC Optical Fiber Patch Cord lies in its ability to amalgamate light signals from two separate optical fibers into a unified cable connector. This amalgamation is facilitated by a diminutive ferrule that ensures precise routing of the fibers, thereby enhancing connection density in a given area. A distinctive feature of these connectors is their latching mechanism, which offers a user-friendly advantage over other connector varieties.

Advantages of Employing an LC LC Optical Fiber Patch Cord

The utility of an LC LC Optical Fiber Patch Cord is multifaceted. Primarily, its compact stature allows for a denser arrangement of connections, a critical attribute in space-restricted data centers. It enhances precision in fiber routing and simplifies the task of identifying individual fibers within a network, courtesy of its latching mechanism. The widespread availability of LC connector options further extends its appeal.

Moreover, the diminutive size of LC connectors translates to lower power consumption compared to other connector types, which can lead to reduced operational costs in fiber network systems. These combined features elevate the LC connector to a position of prominence among fiber optic connection solutions in the current market.

In sum, LC LC Optical Fiber Patch Cords stand as formidable solutions in the arenas of fiber optics and data center operations. Their compact design, coupled with user-friendly latching mechanisms and precise ferrules, offer significant convenience in fiber identification and routing. Their energy-efficient nature, paired with the ability to accommodate more connections in confined spaces, makes them particularly suitable for data centers with spatial limitations. For those in pursuit of reliable and efficient fiber optic connection methods, LC connectors are a compelling option to consider.
