Cat 5e SFTP Patch Cable

Description

What is CAT 5E SFTP Patch Cord?

Cat 5e SFTP Patch Cord, a product of SFTP Patch Cord Manufacturer, represents an advanced iteration of the Cat 5 design, integrating enhanced far-end crosstalk specifications. Initiated in 2001 within the TIA/EIA-568-B framework, this standard supersedes the obsolete Cat5 criteria. Featuring a robust composition, the cable boasts 1Gbps capacity with RJ45 Male to Male Shielded Connectors, complemented by 50μ Gold Plated contacts. Its construction includes Twisted pairs augmented with a central spine, enveloped in a Double Foil shield and a Drain wire steel earth lead, all encased in a durable and pliable Blue PVC jacket, customizable in color.

Despite its alignment with the 1000BASE-T design, originally intended for Cat5, Cat 5e SFTP cables and connectors, due to their refined specifications, emerge as superior alternatives for 1000BASE-T applications. However, it's crucial to note that these enhanced performance parameters don't extend the permissible cable length for Ethernet networks, which remains capped at approximately 328+ ft (100+ m). This limitation is with a standard practice of restricting fixed ("horizontal") cables to 90 m, accommodating up to 5 m of patch cable at each end. The performance attributes and testing methodologies of Cat 5e SFTP cable are meticulously detailed in TIA/EIA-568-B.2-2001.

Application

Primarily employed in Equipment Rooms, Telecommunication Closets, and Work Areas.

Specifications & Unique Features

• Conductor: 26 AWG stranded copper wires
• Insulation: High-density PE
• Shielding: Polyester-Aluminum foil ensuring 100% coverage
• Additional Shield: Tinned copper wire braid with a 26 AWG drain wire
• Jacket: Flame retardant PVC, with an option for Low Smoke Zero Halogen (LSZH)
• Compliance: Meets TIA/EIA-568-B.2 Cat.5e Standard
• Certifications: UL/CSA/CE
• Jacket Color: Customizable upon request

Wiring Cat5e SFTP Patch Cords

In the era where wireless networks are ubiquitous, the reliability and speed of wired networks, particularly in homes and businesses, remain unparalleled. Wiring these networks involves managing a multitude of incoming cables, and here, Cat 5e SFTP patch panels from SFTP Patch Cord Manufacturers play a pivotal role. They centralize these cables, simplifying network management tasks like modifications or expansions.

The market offers various fiber and copper patch panels. Copper ones cater to both shielded and unshielded cables, including Cat5e, Cat6, Cat6a, and Cat7. This guide focuses on Cat5e patch panels, delineating the wiring process.

Essentials for Wiring Cat5e Patch Panels

• Cat5e Patch Cable: Vital for connecting devices to patch panel ports and interlinking panels. The design and quality of Cat5e patch cables' terminations are crucial. Options include booted cables for protecting the tab and non-booted ones for less frequent unplugging scenarios.
• Cat5e Patch Panel: Serving as a hub in a LAN, it houses ports to manage Ethernet cables and complies with TIA/EIA 568 specifications. Cat5e panels come in shielded variants for high EMI environments and unshielded for standard settings. They are available in punch-down and feedthrough configurations.
• Tools for Wiring: Including cable strippers for jacket removal, and network cable testers to ensure proper connections and communication strength.

Cat5e Patch Panel Wiring Procedure

• Inspect the Patch Panel: Check the 110-style punch down connectors.
• Strip Cable Jackets: Remove about 1 inch of the jacket from each cable end.
• Organize Cable Wires: Untwist the pairs and arrange the eight wires.
• Insert Wires into Connectors: Follow the color-coded labels for correct placement.
• Terminate the Wires: Use a punch-down tool to secure the wires and trim excess.
• Label the Cables: Optional, but aids in identifying cable origins.
• Test the Connections: Ensure proper termination with a cable tester.

Conclusion Proper preparation and understanding of Cat5e patch panels, cables, and the necessary tools are essential for efficient wiring. This guide offers an overview of the technical aspects and steps involved in the wiring process, catering to the needs of those looking to establish a robust wired network setup.

Custom CAT5E SFTP Patch Cord Manufacturer In China

At Excellence Wire, we specialize in crafting UTP, FTP, and SFTP RJ45 patch cords, particularly focusing on Category 5e RJ45 copper cabling systems. Our portfolio of LAN patch cords aligns with numerous global standards, including UL and CE certifications. They have successfully undergone rigorous testing, including the Fluke component and channel tests, with test reports accessible upon request. As a custom patch cord manufacturer, we excel in providing tailored solutions for both OEM and ODM RJ45 patch cords, offering competitive pricing for the specific requirements you have.

Customization Options for OEM and ODM RJ45 Patch Cord:

• Type of Cord: Choose between patch cord or bulk cable.
• Ethernet Category: Options include Cat.5e, Cat.6, Cat.6A, Cat.8.
• Cable Construction: Twisted pair and shielding varieties such as UTP, STP, U/FTP, F/UTP, S/UTP, SF/UTP, or S/FTP.
• Patch Cord Style: Select from molded patch cords or assembled patch cords.
• Plug Design: Options for molded plug boot design and appearance.
• Material of Plug Housing: Available in UL 94V-0 or UL 94V-2.
• Plug Housing Colors: A range including clear (transparent), black, blue, green, yellow, red, or custom options.
• Gold Plating Thickness: Ranges from 3 to 50 microinches.
• Contact Pins: Choose between 2 prong pins for stranded cables or 3 prong patented pins for both solid and stranded cables.
• Cable Jacket Material: Options include PVC, LSZH, or antibacterial materials.
• Cable Jacket Colors: A spectrum of choices like grey, black, blue, green, yellow, pink, red, orange, purple, blue, or customized hues.

For those seeking custom cat 5e patch cords or cat 5e sftp patch cords, Excellence Wire stands ready to meet your specific needs with high-quality, customizable solutions.
